HDPE return idlers are engineered to support the return side of conveyor belts with exceptional durability and efficiency. Manufactured from high-quality HDPE, these idlers are significantly lighter than conventional steel idlers, reducing installation effort and overall conveyor load. An improved bearing and sealing arrangement minimizes contamination ingress, lowers rolling resistance, and extends service life, making them ideal for demanding mining and industrial environments.

SPECIFICATIONS
IDLER DIAMETER (D): 127
FACE LENGTH (FL): 1146
SHELL WALL THICKNESS (WT): 11.5
SHAFT DIAMETER (SD): 25
SHAFT LENGTH (SL): 1190
SHAFT MOUNTING CENTRE (MC): 1168
SHAFT SLOTTED WIDTH (CW): 12
SHAFT SLOT (CD): 18
PRODUCT NAMES: CONVEYOR FLAT RETURN IDLER
BELT WIDTH (mm): 1050
MATERIAL: HDPE ROLLER
COATING: BLACK HDPE
STANDARDS: SANS 1313-SERIES 25
SHAFT MOUNTING: CLOSED END-SLOTTED
BEARING TYPE: 6205 2RS C3 BEARINGS
BEARING FIX: EXTERNAL CIRCLIP
SEALS: ANTI-SEIZE LAB
CAPS: ROCK SHIELD
All dimensions are in mm
