CONVEYOR BELT 450MM – EP 400/3 T5 + B1.6 conveyor belt is engineered for reliable, low‑maintenance material handling in demanding industrial environments. Key features include width 450MM, tensile rating 405, top cover 5.0, bottom cover 1.6. Suitable for mining, quarrying, and bulk‑handling conveyors.

PRODUCT NAMES: CONVEYOR BELT
Class: 400
Belt Width: 450mm
Number of Piles: 3
Coneveyor Material Type: Rubber
REINFORCED MATERIAL: EP – E:Polyester P: Plyamide/Nylon
TOP COVER (mm): 5.0
SKIM RUBBER (mm): 1.65
BOTTOM COVER (mm): 1.6
TOTAL THICKNESS (mm): 10
MINIMUM DRIVE PULLEY DIAMETER (mm): 400
MINIMUM TAIL/TAKE-UP PULLY DIAMETER (mm): 315
MINIMUM SNUB PULLEY DIAMETER (mm): 250
TENSILE STRENGTH (kN/m): 405
WORKING TENSION (N/mm): 40.5
ELONGATION (STRETCH L=10m) (mm): 0.2
QTY equals Meter required.
